KEMMLER tapping chuck VDI30 M3-M14 without compensation

Name: KEMMLER tapping chuck VDI30 M3-M14 without compensation
Brand: KEMMLER
SKU: 22740095

Brand: KEMMLER

All versions

Individual prices for customers after login

Art.-no. 22740095

Quantity

Price per

Piece

You need more information or have not found your desired product?

Application

For machining centres with synchronous spindles. To accommodate quick-change inserts for screw taps

Execution

Alloyed case-hardening steel with a core tensile strength of at least 950 N/mm²
Case-hardened, HRC 60 ± 2 (HV 700 ± 50)
Hardness depth 0.8 mm ±0.2 mm
black-oxide and precision-ground finish
With internal coolant supply or with threaded connection for external coolant supply
without length compensation under compression and tension

Notes

Previous standard DIN 69880/VDI 3525

Delivery

1x VDI tapping chuck without compensation; without quick-change inserts
