KROEPLIN quick probe D220S 0 20 mm, 0.01 mm, IP65, for external measurements - Quick probe for external measurement

KROEPLIN quick probe D220S 0 20 mm, 0.01 mm, IP65, for external measurements - Quick probe for external measurement - 1

KROEPLIN quick probe D220S 0 20 mm, 0.01 mm, IP65, for external measurements - Quick probe for external measurement - 2

KROEPLIN quick probe D220S 0 20 mm, 0.01 mm, IP65, for external measurements

Name: KROEPLIN quick probe D220S 0 20 mm, 0.01 mm, IP65, for external measurements
Brand: KROEPLIN
SKU: 33241050

Brand: KROEPLIN

Art.-no. 33241050

Manufacturer article no. D220S

All versions

Similar products

Individual prices for customers after login

KROEPLIN quick probe D220S 0 20 mm, 0.01 mm, IP65, for external measurements

Art.-no. 33241050

Quantity

Price per

Piece

You need more information or have not found your desired product?

Login/Register
Call customer service: +33 (0)1 69 19 43 90

Application

For measuring thicknesses, wall thicknesses and external grooves.

Execution

Adjustable tolerance marks
Easy adjustment with rotating housing
1 fixed and 1 movable measuring arm

Advantage

Manufacturer's warranty extension: If registered on the manufacturer's website within three months of the date of purchase, the manufacturer's warranty is extended by one year. Instructions for this are included in the scope of delivery.

Delivery

With traceable test certificate in box

Product information

HAHN+KOLB Catalogue

Certificates/ Documents


Brand	KROEPLIN
Manufacturer Part Number	D220S
Min./max. length measuring range	0-20 mm
Scale value	0.01 mm
Display	Analogue
Measuring depth	85 mm
Type	D220S
Measuring arrangement	7
Measuring contact length movable (Hb)	24.7 mm
Measuring contact length fixed (Hf)	24.6 mm
IP protection class	IP 65
Data transmission type	No
Gross Weight	0.540 kg
