WIDIA Top Cut 4 indexable inserts, internal, V38, TCF060203BCV38 WU40PH
Brand: WIDIA
Surface: TiAlN
Art.-no. 11214090
Manufacturer article no. 6429459
EAN 4059782484986
Individual prices for customers after login
Application
First choice for long-chipping materials such as long-chipping steel with low carbon content, stainless steel, superalloys and titanium grades 2 and 5
Advantage
- No build-up of chips on the tool
- No vibration thanks to good chip flow
- No contact with chips therefore no damage to surfaces
- Lower power consumption and torque required
Brand | WIDIA |
Main EAN Code | 4059782484986 |
Manufacturer Part Number | 6429459 |
Cutting material | SC |
Surface | TiAlN |
Suitable for indexable inserts type | B |
Size of indexable insert | 6 mm |
Inner circle diameter | 2.4 mm |
Cutting width | 4.9 mm |
Thickness of indexable insert | 2.4 mm |
Corner radius | 0.3 mm |
Clearance angle | 11 Degree |
Carbide type | WU40PH |
Gross Weight | 0.001 kg |
